Graphite Design

Graphite Design Tour AD XC [ Driver + Wood Shaft ]

Graphite Design Tour AD XC [ Driver + Wood Shaft ]

Regular price $379.00 USD
Regular price Sale price $379.00 USD
Sale Sold out

Wood/Driver Shaft Customization
Free with Club Purchase

Enhance your performance with our complimentary shaft customization service. With your club purchase, we’ll tailor your shaft to fit your exact specs — at no extra cost.

Already added a shaft to your cart?
Be sure to click [here] to customize your shaft — select your preferred loft, adapter, and length so we can build it just right for you.

View full details

Introducing Graphite Design Tour AD XC Shaft. A strong sense of acceleration that takes advantage of the performance of the head and a sense of acceleration toward impact.

The "TOUR AD XC" series is a new shaft that maximizes the distance-pursuit typeface structure that is currently the mainstream of wood. By using the new material carbon trading card "M40X" from the tip to the middle part and using the trading card "T1100G" at the tip, the power loss at the time of impact is reduced to the utmost and the tip behavior is stable.
Bending from the middle part to the hand part, which is peculiar to the original tone shaft, improves operability, gives a strong bending back and a feeling of acceleration, and has stable behavior that does not lose even a strong impact, head performance.

TECHNICAL SPECS

Series Flex Desc Wt(q) Torque (Deg) Tip Dia(mm) Tip Para(mm) Butt Dia(mm) Kick Point Shaft Length (mm)
XC-4 R2 LITE/SENIOR 47.0 5.7 8.50 75.0 15.05 MID HIGH 1168
XC-4 R1 REGULAR 47.0 5.7 8.50 75.0 15.05 MID HIGH 1168
XC-4 S STIFF 48.0 5.7 8.50 75.0 15.05 MID HIGH 1168
XC-5 R2 LITE/SENIOR 54.0 4.3 8.50 75.0 15.10 MID HIGH 1168
XC-5 R1 REGULAR 54.0 4.2 8.50 75.0 15.10 MID HIGH 1168
XC-5 S STIFF 56.0 4.2 8.50 75.0 15.15 MID HIGH 1168
XC-5 X X-STIFF 58.0 4.2 8.50 75.0 15.25 MID HIGH 1168
XC-6 SR STIFF REGULAR 62.0 3.2 8.50 75.0 15.15 MID HIGH 1168
XC-6 S STIFF 64.0 3.2 8.50 75.0 15.20 MID HIGH 1168
XC-6 X X-STIFF 65.0 3.2 8.50 75.0 15.25 MID HIGH 1168
XC-7 S STIFF 73.0 3.0 8.50 75.0 15.20 MID HIGH 1168
XC-7 X X-STIFF 75.0 3.0 8.50 75.0 15.25 MID HIGH 1168
XC-8 S STIFF 83.0 2.8 8.50 75.0 15.35 MID HIGH 1168
XC-8 X X-STIFF 85.0 2.8 8.50 75.0 15.40 MID HIGH 1168
